The specialist small wave prone foil
This unique design features a dihedral, or V–shape where the foil joins the mast. When the foil is rolled over in a turn, this has the effect of reducing lift generated from the opposite side of the foil, as it will be on a more vertical angle. This greatly assists tight carving and loose turning when Prone, SUP, Wing, Wind, Tow or Kite foiling.

The foil section is the same as the AXIS PNG range (thinner, high camber), further maximising it’s small or slow wave prowess and ability to achieve the holy grail – pumping back out and straight onto the next wave.

SP is not only for small wave riding. These wings are tons of fun for wing foiling (SP 860), windsurfing, kite foiling or towed behind a boat. When super loose riding is what you are looking for, the AXIS SP wings make it all possible.

SP foils are ideally matched with our Freeride Small rear wing range.
Sizes
660 – Addresses the need of experienced surf foilers to ride bigger waves, with loose side to side turning and higher speeds. Turning fast and effortlessly, it gives the rider the closest possible feeling of a riding a surf board. It’s balance neutral, without requiring more front foot pressure as you carve or surf waves at speed.
Recommended for: Prone foiling bigger waves, Tow-in foiling, Kite Foiling freeride or waves.

760 – Allows you to handle more juice in bigger and steeper conditions, while maintain control and loose turning. The 760 will be your choice when the waves are sucky and steep or close together with lots of link ups. Full skatepark mode. Other than prone, the AXIS 760 carbon wing is a fantastic wave and cruise style kite foiling wing. You can ride is as slow as you want, turns on a dime, and you can still push it on those faster downwinders. A perfect one wing kite setup.
Recommended for: Prone foiling bigger waves, Tow-in foiling, Kite Foiling freeride or waves.

860 – Addresses the need of foil surfers for fast and loose turns on medium to small size waves. Also a fantastic wave and cruise style kite foiling wing for lighter days. You can ride is as slow as you want, turns on a dime, and you can still push it on those faster downwinders. A perfect one wing kite setup which excels in the lightest of the wind. The 860 can also be high performance SUP wing for bigger days or lighter riders. And if it gets really windy, the 860 can be the surfiest Wing Surfing wing you have ever used.
Recommended for: Prone foiling medium / small waves, Kite Foiling freeride or waves in might or medium winds, SUP foiling on bigger days, Wing surfing on bigger days.
Specification

WINGSPAN
CHORD
AREA
ASPECT RATIO
PROJECTED AREA
VOLUME

660 mm
200 mm
1113 cm²
6.49
1034 cm²
1582 cm³

760 mm
190 mm
1218 cm²
5.11
1130 cm²
1673 cm³

860 mm
180 mm
1293 cm²
6.10
1212 cm²
1700 cm³
